Our premium glazing collection defined by exceptional craftsmanship, refined design, and enduring quality. Made for bold architecture and uncompromising vision.
A bold architectural statement—rotating on a vertical axis to create wide, fluid openings with minimal framing and expansive glass. Its unique pivoting mechanism supports large-scale panels with ease, offering seamless transitions between spaces. Whether as a grand entrance or refined interior feature, it transforms how architecture moves, connects, and feels.
With ultra-slim framing and clean edges, the Fluid X Pivot Door achieves visual lightness even at oversized dimensions. It appears to float within the architecture, becoming both feature and function in one refined gesture.
- Sightlines : 45 mm
- Max Leaf Height : 5 m
- Max Leaf Weight : 500 kg
- Max Area / Leaf : 8 m²
- Max Glass Thickness : 44 mm
- Frame integrated handle
- Multipoint locking
- Integrated slot drain available
- External and internal locking
- Micro-ventilation
- Multi-Point Lock
- RAL colours
- Anodised finishes
- Thermal Coefficient Uw : 1,1 W/m² K
- Sound Insulation : Up to 41 dB
- Water Tightness : Class 9A
- Air Tightness : Class 4
- Wind Tightness : Class C5
The pivot door introduces a sculptural clarity to architectural thresholds—replacing traditional hinges with a vertical rotation point that creates clean lines and uninterrupted views. It allows for striking proportions while retaining a minimal visual presence, whether surrounded by solid walls or adjacent to full-height glazing. By replicating the sightlines of adjoining systems, the door maintains a cohesive design language throughout the project.
Effortless Motion, Expansive Openings
Thanks to a concealed pivot mechanism, the door opens with precision and grace, rotating up to 360° where required. The wide arc of movement enables both practical access and sculptural drama, offering a heightened sense of entry and transition.
Continuity of Language
The Fluid X Pivot Door can be mirrored across a project—used not only as a feature entrance but also as an internal pivoting window system, maintaining a consistent aesthetic and spatial rhythm throughout.
True to the Fluid X philosophy, the pivot door is crafted for clarity, proportion, and expression. Available in a range of configurations—from full-height glazed panels to solid or mixed-material inserts—it adapts seamlessly to its architectural setting. Handle options vary to suit context and style, ensuring both tactile comfort and visual harmony.
Behind its quiet elegance lies advanced engineering. The Fluid X Pivot Door is designed to support large-scale panels while delivering security, comfort, and long-term durability. Multi-point locking systems—available in manual or electromagnetic versions—ensure secure closure, while access control options support a range of operational needs, from residential to commercial applications.
Precision Pivot System
Capable of supporting tall, heavy doors, the pivot hardware is discreetly integrated within the floor and ceiling. This allows the door to open smoothly and reliably, with balanced weight distribution and minimal mechanical resistance.
Thermal and Acoustic Integrity
High-specification glazing—double or triple units with low-emissivity coatings—delivers outstanding thermal insulation, while integrated seals and acoustic interlayers enhance comfort, reduce noise, and resist the elements. The system is designed for everyday performance with premium detailing.
